Spot Ionizer IonONE

Model Micro S Spot Ionizer is suited for applications where airflow from HEPA filters or fans is present, or when the area to be protected is in close proximity. Simco-Ion's Model Micro SA Spot Ionizer uses compressed dry air (CDA) to provide the airflow necessary to ionize a nearby confined area when there is no existing airflow.

Features

  • Compact design
  • Self-balancing technology
  • Easy maintenance
  • Power Indicator status LED
  • Air assist version for precise ionized air delivery

Specifications

Spot Ionizer IonONE

Input Voltage Isolated 12 VDC, 30 mA
Discharge Micro S: <10 sec @ 3" (76 mm); Micro SA: <8 sec @ 6" (150 mm), 20 lpm airflow (min)
Balance Micro S: <±30V; Micro SA: <±20V
Coverage Micro S: 6" x 6" (150 x 150 mm) @ 3"; Micro SA: 6" x 6" (150 x 150 mm) @ 6"
Cleanliness Meets ISO 14644-1 Class 5 (Fed. Std. 209E Class 100)
Dimension 2L x 1.6W x .65H" (52 x 41 x 16.5 mm) flange adds 0.24" (6 mm) to length on each end; air fitting connection on Micro SA adds 0.40" (10 mm) to length of chassis
Weight Micro S: 0.56 oz (16g); Micro SA: 0.67 oz (19g)
